Description:
Double sided PCB board for tablets comes with 1.6mm board thickness and immersion gold surface finish, ONE piece order accepted.
andnbsp;
Currently, the use of the tablets is common as the cell phones but the large screen function is more popular. Tablet producers need more stable and long lifespanandnbsp;printed circuit boardandnbsp;to support the large screen.
andnbsp;
Here is the smart choice for you,andnbsp;double sided PCB boardandnbsp;for tablets comes with 1.6mm board thickness and immersion gold surface finish, ONE piece order accepted.
andnbsp;
andnbsp;
Specification:
|
andnbsp;andnbsp;andnbsp;andnbsp; Specifications
|
andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp; andnbsp;Details
|
|
Material Type
|
FR-4, CEM-1, CEM-3, Aluminum Clad, Argon*, Teflon, Taconic, Rogers*, Polyimide*, Kempton, DuPont
|
|
Material Thickness
|
Min. thickness: 0.4mm(16mil)
Max. thickness: 3.2mm(128mil)
|
|
Layer count
|
1 to 28 Layers
|
|
Max. Board Size
|
23.00andquot; x 35.00andquot;(580mm*900mm)
|
|
IPC Class
|
Class II, Class III ,andnbsp; Class 1
|
|
Annular Ring
|
5 mil/side or Greater (Min. Design)
|
|
Finish Plating
|
Solder(HASL), Lead Free Solder(HASL), ENIG (ELectroless Nickel Immersion Gold), OSP, Immersion Silver, Immersion Tin, Immersion Nickel, Hard Gold,andnbsp; Other
|
|
Copper Weight
|
0.5OZ-7OZ
|
|
Trace/Space Width
|
3 Mils or Greater
|
|
Drill Clearance
|
0.1mm(laser drilling)
|
|
Plated Slots
|
0.036 or Greater
|
|
Smallest Hole (Finished)
|
0.1mm or Greater
|
|
Gold Fingers
|
1 to 4 Edge (30 to 50 Micron Gold)
|
|
SMD Pitch
|
0.080andquot; -andnbsp; 0.020andquot; -andnbsp; 0.010andquot;
|
|
Solder mask Type
|
LPI Glossy, LPI-Matte, SR1000
|
|
Solder mask Color
|
Green, Red, Blue, Black, White, Yellow,
|
|
Legend Color
|
White, Yellow, Black, Red, Blue
|
|
CNC Route Point
|
Any
|
|
Minimum Route Width
|
0.031andquot;
|
|
Scoring
|
Straight Lines, Jump Scoring, Panel Edge to Edge, CNC*
|
|
Body Gold
|
HARD*, IMMERSION* (up to 50 MICRON GOLD)
|
|
Data File Format
|
Gerber 274x with embedded aperture
|
|
Fab. Drawing Format
|
DXF, HPGL, DWG, PDF, Gerber
|
|
E.T Testing
|
Flying Probe, Single Sided, 1up Plate, Clamshell, Net List
|
|
Counter Sink / Counter Bore
|
Available up to 0.250 Diameter
|
|
Control Impedance
|
Yes
|
|
Blind Vias / Buried Vias
|
Yes
|
|
Peelable Mask
|
Yes
|
|
Carbon
|
Yes
|
andnbsp;
andnbsp;
andnbsp;
Feature:
andnbsp;
andmiddot;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp; Layers: 2L
andmiddot;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp; Material: FR4
andmiddot;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp; Board Thickness: 1.60mm
andmiddot;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp; Surface Finish: HASL lead free
andmiddot;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp; Surface Finish : Immersion Gold
andmiddot;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp; Min Line Width : 0.075mm(3 mil)
andmiddot;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp; Min Line Space : 0.075mm(3 mil)
andmiddot;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp;andnbsp; Special Requirements : Board Thickness 0.40mm+/-0.05mm
andnbsp;
andnbsp;
Application:
andnbsp;
The PCBs are used for wide range of electronic products:
They are including autoandnbsp;partsandnbsp;products,andnbsp;medicalandnbsp;equipment,andnbsp;precisionandnbsp;instruments,andnbsp;aviationandnbsp;equipment,andnbsp;andandnbsp;otherandnbsp;fields
Product show:
andnbsp;
The PCB factory which we cooperated has more than 14 yearsandnbsp;of Experience in PCB Industry,
There are more than 600 employees and four factories; one factory for prototypes, one for mass production, one for aluminum and copper PCBs, and one for PCB assembly. Each factory has the ability to make 8,000 square meters per month and we offer 1,000 kinds of PCB fabrication monthly, including one- to 20-layer PCBs, HDI, aluminum, heavy copper and halogen-free PCBs.
andnbsp;
we haveandnbsp;Double-sided cooperation with the PCB factory,our company offer them a series electronic components and other parts for BOM, and we make PCB and assembly there.so both of us can get veryandnbsp;competitive price.
andnbsp;
With the powerful support from the partner, weandnbsp;Have confidenceandnbsp;to give our customers best service.
